- Multi-style inner core design (2-8 cores), in line with various industrial requirements, the signal and power supply are compatible at the same time.
- Spring-pressed design, tightly docked, safe and secure.
- The orientation is strong, and blind insertion can be realized, and the humanized design in the true sense.
-3 core lock screws and solderable optional connection, fully compatible with outdoor installation work.
- Gold-plated contacts, high corrosion resistance and electrical conductivity, effectively coping with changes in temperature rise caused by current.
- Thermoplastic high temperature resistant plastic case, stable electrical performance, high strength, high temperature resistance and corrosion resistance.
- Unique docking design, solid extension of infinite line length.
-Flange 4 hole mounting, stable and impeccable, threaded single hole housing installation, suitable for circular opening industrial installation.
- The product complies with IP67 protection in the assembled state.
Specifications
CNLINKO plastic 8 pin ip67 waterproof panel mount cable female to female connector
Specifications | |
Connecting mode | Latching Lock connect |
Protection level | IP65/IP67 |
Cable specification | 0.2~0.3mm²/24~22AWG |
Diameter range | Φ3mm ~Φ6mm |
Contact diameter×Qty | Φ0.8x8 |
Current rating(A) | 3A |
Temperature rise | / |
Withstanding voltage(AC.V)1min | 1500V |
Contact resistance | <5mΩ |
Insulation resistance | >500MΩ |
Durability | ≥500 mating&unmating cycles |
Temperature rating | -40°C~80°C |
Method of connecting cable | Soldering |
Prevent the combustion level | UL94-V0 |
Material | |
Insulated parts | High performance engineering plastics |
Hardware metal | Zinc alloy(pearl hard chromium) |
Contact pin | Copper alloy(gold-plated 4U) |
Spring | Stainless steel |
Sealing | Silica gel |
Main characteristics | |
Sealed against dust and fluid (IP65/IP67) | |
Vibration resistance,impact resistance,stretching resistance | |
socket with cover | |
Application industries | |
Stage equipment - The smart grid | |
Medical equipment - Server | |
Solar energy equipment - Ship equipment | |
Electric power equipment - Vehicle equipment | |
Communications equipment - Heavy machinery |
